Description

Description

• An economical choice for leveling, backfilling, grading and removing snow on farms or acreages
• This implement does not require PTO
• Blade can be rotated 360 degrees and angled to move material from either side
• Use the blade in forward or reverse

Features

• Rotate and Reverse: The 3-point angle blade rotates a full 360 degrees with five forward and five reverse settings to be pulled or pushed.
• Four Widths: Available in 60-inch, 72-inch, 84-inch, and 96-inch blade widths
• Category 1, 3-Point Hitch: A 3-point hitch is used to attach your rear-mounted angle blade implement. An adjustable top link is centered above two lower link arms, comprising the three points. The angle blade implement quickly and easily attaches with connecting pins at each point.

Specifications

• Moldboard Width: 60″
• Length: 40″
• Moldboard Dimension: 15″
• Cutting Edge: 6″
• Hitch: Cat I
• Adjustment Types: Manual (360 Degree Rotation)
• Operating Weight: 308 lbs
• Width: 60″
• Offset (Max): 12″ Left or Right
• Forward Pivot: 5 Positions (7 Degrees Each)
• Reverse Pivot: 5 Positions (7 Degrees Each)
