Description

Description

This 25-hp compact tractor provides hydrostatic transmission (HST) or manual-shift transmission (MST) options. Loader is included in price.

Features

• Strong enough for big jobs but small enough to fit into tight areas
• Open workstation with Roll-Over Protective Structure (ROPS)
• Category 1 three-point hitch for using implements
• Integrated loader joystick lever makes front-end loader work easier
• Standard rear PTO/optional mid-PTO
• Count on rugged performance, power, comfort and all-around versatility for small farms, ranches and acreages with the economical CT2025 compact tractor.
• With standard four-wheel drive, this tractor is ideal for hauling material, digging holes, mowing and using implements.
• Climb on and off the tractor with ease thanks to the open cab.
• Pick the controls that fit your working style. The CT2025 offers options for 3-Range hydrostatic transmission or manual-shift transmission
• The integrated joystick lever is within easy reach and makes the font-end loader respond intuitively to your command.

Specifications

Engine

• Horsepower: 24.5 hp
• Displacement: 100 in³
• Number of Cylinders: 3
• Gross HP: 24.5 hp
• Engine Model: 3A165LWM(H)
• Emissions Tier (EPA): Tier 4

Performance

• Operating Weight: 2,634 lbs
• Travel Speed: 9.5 mph
• Travel Speed – Reverse: 6.5 mph
• 3-Point Hitch: Category 1
• 3-pt Lift Control Type: Hydraulic Position Control System
• Lift Capacity at 24″ behind Lift Point: 1,631 lbs
• Rear PTO System: Live
• Rear PTO – RPM: 540
• PTO HP: 21.8 hp
• Mid PTO – RPM: 1976

Transmission

• Type: Infinite, 3 Range Hydrostatic
• Brake Type: Wet Multi-Disc

Capacities

• Fuel Tank: 9 gal

Hydraulic System

• Implement Hydraulic Flow: 6.9 gal/min
• Total Hydraulic Flow: 11.4 gal/min
• Steering Hydraulic Flow: 4.5 gal/min

Dimensions

• Width: 63.4 in
• Ground Clearance: 11.7 in
• Turning Radius: 8′ 0″
• Wheelbase: 5′ 5″
• Front Tire Size: 25X8.5-14 (7-16, 27X8.5-15)
• Rear Tire Size: 15-19.5 (11.2-24, 41X14-20)

Loader Attachment

• Loader Lift Height: 7′ 10″
• Lift Capacity at Bucket Pivot: 1,369 lbs
• Bucket Width: 5′ 0″
