Description
The Goal of the Kozy King is to serve your needs with a very efficient, clean burning furnace to heat your home. The Kozy-King’s secondary combustion provides maximum efficiency with less fuel. This U-L Listed Coal and Wood burning furnace is thermostat controlled for even temperature. The Kozy-King comes with a 3-speed blower and a safety feature to prevent overheating. The DS Circulator rests inside the firebox and is insulated with a sheet metal jacket. You can use this unit independently or in conjunction with another furnace. The Kozy-King will heat your whole house, shop or greenhouse.
Features
- Burns coal and wood
- #300-09 heats
- Superior cast iron shaker grates
- Cast iron airtight doors
- Large loading door
- Large Ash Pan
- 3-speed blower
- Thermostat controlled
- Safety control with fan limit switch
- Cast iron baffle
- Secondary combustion system
- Special tubes through fire box for maximum heat circulation
- Forced draft
- Clean air filter
- 85.1%efficiency rating
- Insulated cabinet
- Made in the USA
Specifications
Fuel Coal and Wood
Heating Area: 3,000 sq. ft.
Efficiency 85.1%
BTU approximately 140,000
Firebox Size (WxD) 16″ x 22″
Log Size 20″
Overall size (W x D x H) 28.5″ x 29″ x 53″
Depth including filter Box 49″
Load Door Size (W x H) 14″ x 14.5″
Ash Door Size (W x H) 16.5″ x 5.5″
Top Exhaust Not available for this unit
Rear Exhaust 8″ – 47″ center of Flue
Plenum inlet and outlet 18″ x 18″
Blower CFM 3 speed (1,100, 1,350, 1,650)
UL Tested Yes
Weight 730 lbs
Insulated Jacket Standard
Warranty 5-year limited and 1-year electrical
Clearances From Combustibles
Side 18″
Back 18″
Front 48″
Flue/Stove pipe 18″
Top of plenum to ceiling 2″
PDF DS FURNACE SPECIFICATIONS AND DIMENSIONS
