Toro Ribbed Auger Drive Belt (Part #138-8723) For 21″ Power Clear Single-Stage Snowblowers

Description

Please refer to the Images above; Product Specifications, Associate Part Chart and the Model Fit Guide below to Ensure a proper fit.

• PRODUCT NUMBER AND VARIATIONS: 138-8723, 138 8723, 1388723
• PRODUCT TYPE: Ribbed Auger/Rotor Drive Belt
• SIZE: Length N/A in. – Width N/A in. – Height N/A in. – Weight 0.126 lbs.
• NOTES & DETAILS: Toro OEM  138-8723 IS COMMINLY USED – 138-8723 Travels from the Engine Pulley to the Auger/Rotor Pulley – Rotates the Auger When Pressure is Applied by the Tensioner Idler Pulley.
• COMMON SERIES APPLICATIONS: Toro Select 21″ Power Clear Snow Blower Models.

• MODEL FIT CHART:

SNOWBLOWER’S

POWER CLEAR Series – Model Numbers – (* Model Numbers 38752, 38753, 38754, 38755, 38756, 38757)

• ASSOCIATED PARTS CHART:

ASSOCIATED PARTS REFERENCES FOR PART NUMBER 138-8723 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED

1. 138-8772 – ENGINE PULLEY (Is Assembled Directly to the Engine Crankshaft and Enables the Engine to Rotate the Auger/Rotor when the Operator Applies Tension on the Auger/Rotor Drive Belt by Engaging the Auger/Rotor Clutch Bail Handle) x1 Per Snowblower Unit
2. 138-8720 – AUGER/ROTOR PULLEY (Is Assembled Directly to the Auger/Rotor Assembly Shaft and Enables the Auger/Rotor to Rotate when the Operator Applies Tension on the Auger/Rotor Drive Belt by Engaging the Auger/Rotor Clutch Bail Handle) x1 Per Snowblower Unit
3. 139-3513 – IDLER PULLEY (Maintains Roller Bearing that Allow the Pulley to Match the Speed of the Engine RPM’s as the Operator Applies Direct Tension Between the Belt and Idler Pulley while Engaging the Auger or Rotor – Fastens Directly on the Outside side of the Idler Pulley Tensioner Arm) x1 Per Snowblower Unit
