Ds Stoker Coal Furnace System

Description

Stoker Furnace

Model #DS SF250

The Stoker Furnace is a twin to the Stoker Boiler that we manufacture. The differenceis “hot air” vs. “hot water”. It is an auger-fed stoker with a pot burner, designed to burn rice coal. It is designed to feed the coal from an optional 500 lb. hopper or coal bin. This unit is constructed with a “built to last” attitude.

• Burns rice coal
• Auger-fed round fire pot with complete breakdown “floating” design
• RH or LH feed option
• Outfire sensor

• Variable speed combustion blower and auger
• Special tubes through the firebox for maximum heat exchange
• Optional 500 lb. hopper
• Made in the USA
• Size 30.75″ W x 36″ D x 51″ H
• 8″ Rear Exhaust
• 850 lbs
• Optional 4 or 5 GPM domestic Coil
